Plan Description
This ranch design floor plan is 3402 sq ft and has 4 bedrooms and 4.5 bathrooms.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 92' 1"
Height : 16' 7"
Width : 47'
Area
Main Floor : 3402 sq/ft
Porch : 45 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 10'
Roof
Primary Pitch : 3:12
Secondary Pitch : 5.5:12
Exterior Wall Framing
Exterior Wall Finish : Board and Batten Siding
Framing : 2x6
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Main Floor Laundry
Mud Room
Sunroom
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Grill Deck Sundeck
Screened Porch
What's Included In This Plan Set
- COVER PAGE: Cover Sheet: Showing architectural rendering of residence
- FOUNDATION PLAN: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- FLOOR PLAN: Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- ROOF PLAN: An overhead "birds-eye" view of the roof, describing roof slope
- ELEVATIONS: A blueprint picture of all four sides showing exterior materials and measurements.
- SECTIONS: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- ELECTRICAL PLAN: Shows the locations of lights, receptacles, switches, etc.
- TYPICAL WALL SECTION & DETAILS
