Plan Description
This farmhouse design floor plan is 2828 sq ft and has 4 bedrooms and 3.5 bathrooms.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 65' 4"
Height : 29' 8"
Width : 67' 7"
Area
Garage : 508 sq/ft
Main Floor : 2000 sq/ft
Porch : 730 sq/ft
Upper Floor : 828 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : 8' & 10' ceilings on main level; tray ceiling in Master Bedroom; two story Foyer.
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Metal
Secondary Pitch : .25/12
Exterior Wall Framing
Exterior Wall Finish : Stone/Siding
Framing : 2 x 4
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Outdoor Kitchen Grill
More
Jack & Jill Bath
