PLAN 120-174
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Floor Plan - Lower Floor
Floor Plan - Other Floor
Full Specs & Features
Dimension
Depth : 53'
Height : 25' 9"
Width : 46' 11"
Area
Bonus: 504 sq/ft height 10'
First Floor: 1421 sq/ft height 10'
Garage: 600 sq/ft height 10'
Porch: 562 sq/ft
Ceiling
Bonus Ceiling : 9'
Main Ceiling : 10'
Roof
Primary Pitch : 12:12
Roof Framing : stick
Roof Type : Shake
Secondary Pitch : 3:12
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Play Flex Room
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Rooms
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
121 sq/ft width 11' x depth 11'
Bonus Room - Unfinished:
176 sq/ft width 11' x depth 16'
Bonus Room - Unfinished:
260 sq/ft width 16' 3" x depth 16'
Dining Room:
135 sq/ft width 11' x depth 12' 4"
Family Room:
288 sq/ft width 15' 3" x depth 18' 11"
Game Room:
389 sq/ft width 20' 9" x depth 18' 9"
Guest Bedroom 1:
185 sq/ft width 12' 11" x depth 14' 4"
Guest Bedroom 2:
142 sq/ft width 11' x depth 12' 11"
Lanai:
202 sq/ft width 16' 6" x depth 12' 3"
Lanai:
225 sq/ft width 18' x depth 12' 6"
Master Bathroom:
60 sq/ft width 7' 7" x depth 8'
Master Suite:
208 sq/ft width 13' x depth 16'
Master Walk-In Closet:
44 sq/ft width 7' 7" x depth 5' 10"
Mechanical/Equipment Room:
68 sq/ft width 9' 5" x depth 7' 3"
Porch - Front:
151 sq/ft width 25' 3" x depth 6'
Potential Finished Basement:
988 sq/ft
What's Included In This Plan Set
- Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
- Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
- Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
- Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
- Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
- Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
- Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
- Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
Plan Set
$895.00
$895.00
$1045.00
$1145.00
$1695.00
Foundation
$0.00
$0.00
$395.00
$395.00
Framing
$0.00
$245.00
Additional Options
$195.00
$395.00
$165.00
$295.00
$39.00
$395.00
$250.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
