PLAN 1017-1

Home > Style > Mediterranean

Key Specs

6780
sq ft

5
Beds

5.5
Baths

2
Floors

4
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

This stunning, award-winning two-story home embraces many unique features. Stylish front steps lead to a veranda with large double-entry front doors. Upon entering, you are treated to a magnificent view of the pool area and beyond through the large pocket sliding-glass doors featured in the living room. A fireplace and built-in shelves grace one wall of the living room. As you pass through the arched opening situated next to a walk-in wet-bar, you enter the over-sized family room with built-in entertainment center, and a second fireplace. Large pocket-sliders open to the covered lanai and outdoor kitchen area. The spacious master suite includes a large sitting area. The luxurious master bath features an over-sized tub and a large dual-head shower area. Two huge walk-in closets and his-and-her water closets complete this bathroom design. The study with built-in bookshelves, large guest-bedroom suite, powder room, pool bath, utility room, and two separate two-car garages complete the first floor. Ride the elevator or climb the grand staircase where you will step onto a bridged walkway offering an outstanding view looking out over the pool and lanai area. A media/game room and three large bedroom suites, each with their own bath give this exceptional design unlimited potential. Note: First story walls are constructed of concrete block; upper stories are 2 x 6 wood-framed.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 126' 2"

Height : 40'

Width : 103'

Area

First Floor: 5060 sq/ft

Second Floor: 1720 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Main Floor Master Bedroom

Kitchen Features

Breakfast Nook

Butler's Pantry

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Main Floor Laundry

Master Sitting Area

Media Room

Open Floor Plan

Sunroom

Garage Features

Side Entry Garage

Outdoor Spaces

Courtyard

Covered Front Porch

Deck

Grill Deck Sundeck

Outdoor Fireplace

Outdoor Kitchen Grill

Screened Porch

Rooms

3rd BR Closet:

45 sq/ft width 5' 10" x depth 7' 10"

Bedroom 2:

208 sq/ft width 16' x depth 13'

Bedroom 2 Closet:

52 sq/ft width 7' 4" x depth 7' 2"

Bedroom 3:

203 sq/ft width 14' 6" x depth 14'

Bedroom 3 Closet:

52 sq/ft width 7' 4" x depth 7' 2"

Bedroom 4:

193 sq/ft width 13' 8" x depth 14' 2"

Bedroom 4 Closet:

50 sq/ft width 5' 9" x depth 8' 10"

Bedroom 5:

177 sq/ft width 14' 10" x depth 12'

Breakfast Room:

144 sq/ft width 12' x depth 12'

Den/Office or Bedroom 1:

193 sq/ft width 13' 10" x depth 14'

Dining Room:

214 sq/ft width 15' 8" x depth 13' 8"

Foyer:

231 sq/ft width 12' x depth 19' 4"

Garage:

505 sq/ft width 23' 4" x depth 21' 8"

Gathering Room:

529 sq/ft width 23' x depth 23'

Kitchen:

292 sq/ft width 15' 8" x depth 18' 8"

Laundry Room:

86 sq/ft width 8' 4" x depth 10' 5"

Living Room:

385 sq/ft width 18' 8" x depth 20' 8"

Master Bedroom:

367 sq/ft width 19' 4" x depth 19'

Master Closet:

121 sq/ft width 7' 8" x depth 15' 10"

Parlor:

58 sq/ft width 11' x depth 5' 4"

Porch - Front:

221 sq/ft width 4' 4" x depth 51' 2"

Study:

193 sq/ft width 13' 10" x depth 14'

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-800-447-0027

Plan Set

CAD Set:
$3556.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Set:
$3556.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set:
$3556.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00

Concrete Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Right-Reading Reverse:
$622.40

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets:
$72.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$80.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$31.20

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
