Key Specs
3115
sq ft
4
Beds
2.5
Baths
2
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 1084-15
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 45'
Height : 30'
Width : 94'
Area
Garage : 2210 sq/ft
Main Floor : 2020 sq/ft
Porch : 1232 sq/ft
Upper Floor : 1085 sq/ft
Ceiling
Garage Ceiling : 16' 6"
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 6/12
Roof Framing : Pre-engineered wood truss
Roof Type : per manufacturer
Secondary Pitch : 3/12 & 4/12
Exterior Wall Framing
Exterior Wall Finish : Per Owner/Builder
Framing : 2x6 wood framing
Insulation : Per local code
Bedroom Features
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Loft
Main Floor Laundry
Workshop
Garage Features
Oversized Garage
RV Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
More
Jack & Jill Bath
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1349.00
$1649.00
Foundation
$0.00
Framing
$0.00
Additional Options
$250.00
$165.00
$39.00
$165.00
