Key Specs
2672
sq ft
4
Beds
3.5
Baths
1
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 472-347
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 65'
Height : 28'
Width : 70'
Area
Basement Unfinished: 2609 sq/ft
First Floor: 2672 sq/ft height 10'
Roof
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Guest Suite
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Rooms
Bedroom 2:
152 sq/ft width 14' 6" x depth 10' 6"
Bedroom 3:
143 sq/ft width 11' x depth 13'
Breakfast Nook:
121 sq/ft width 9' 6" x depth 12' 10"
Dining Room:
144 sq/ft width 12' x depth 12'
Entry:
90 sq/ft width 6' x depth 15'
Family Room:
249 sq/ft width 14' 8" x depth 17'
Guest Bedroom:
121 sq/ft width 11' x depth 11'
Kitchen:
213 sq/ft width 14' 4" x depth 14' 11"
Living Room:
197 sq/ft width 15' x depth 13' 2"
Master Bathroom:
168 sq/ft width 12' x depth 14'
Master Bedroom:
272 sq/ft width 17' x depth 16'
Study:
121 sq/ft width 11' x depth 11'
Utility Room:
48 sq/ft width 8' x depth 6'
What's Included In This Plan Set
- ELECTRICAL SCHEMATIC
- EXTERIOR ELEVATIONS
- CABINET ELEVATIONS
- CEILING FRAMING
- ROOF FRAMING
- FOUNDATION OF CHOICE AS AVAILABLE (SLAB, CRAWLSPACE OR BASEMENT) APPROPRIATE FOUNDATION DETAIL SHEET
- BUILDING CROSS SECTION IF MULTISTORY
- ALSO 4 PAGE FHA DESCRIPTION OF MATERIALS FORM (NOT A MATERIALS LIST OF QUANTITIES)
- GENERIC WALL SECTIONS
-
Note: Reproducible and CAD files are not available if building in Texas, Oklahoma, New Mexico, Louisiana, Tennessee or Alabama. Architect must update and stamp all plans being sent to these states.
Plan Set
$1228.25
Foundation
$0.00
$106.25
$212.50
Framing
$0.00
Additional Options
$255.00
$140.25
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
