PLAN 51-1148
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 56' 2"
Height : 28' 3"
Width : 50'
Area
Basement : 1313 sq/ft
Garage : 485 sq/ft
Main Floor : 1313 sq/ft
Upper Floor : 1339 sq/ft
Ceiling
Garage Ceiling : 10' 6"
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 14:12
Roof Framing : trusses
Secondary Pitch : 14:12
Exterior Wall Framing
Exterior Wall Finish : siding
Framing : 2x6
Bedroom Features
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Butler's Pantry
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Loft
Mud Room
Upstairs Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Screened Porch
Wrap Around Porch
More
Jack & Jill Bath
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Drawn to 1/4" and 1/8" scale.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Layout: Overhead view of roof showing ridges, valleys, and pitch.
- Note: These plans will not contain an electrical layout.
Plan Set
$1742.50
$1912.50
$1997.50
$1997.50
$2295.00
Foundation
$0.00
$340.00
$340.00
$340.00
Framing
$0.00
$212.50
Additional Options
$212.50
$340.00
$340.00
$340.00
$63.75
$140.25
$33.15
$140.25
$255.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
