Plan Description
This craftsman design floor plan is 1076 sq ft and has 3 bedrooms and 2 bathrooms.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 47'
Height : 23' 11"
Width : 29' 6"
Area
First Floor: 1076 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Kitchen Features
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Main Floor Laundry
Open Floor Plan
Storage Area
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
width 10' x depth 10'
Bedroom 3:
width 10' x depth 12'
Dining:
width 10' x depth 14'
Kitchen:
width 8' x depth 10'
Living Room:
width 13' x depth 14'
Master Bedroom:
width 13' x depth 11'
